| MISURA - SIZE | BOX | MASTER BOX | CODE | DN tubo/pipe | DN | H | N° staffe - N° brackets | PN | Kg |
|---|---|---|---|---|---|---|---|---|---|
| 112 - 126 | 1 | - | 5T860010005 | 100 | 3/4'' | 55 | 1 | 16 | 1,74 |
| 112 - 126 | 1 | - | 5T860010006 | 100 | 1'' | 55 | 1 | 16 | 1,66 |
| 112 - 126 | 1 | - | 5T860010007 | 100 | 1''1/4 | 50 | 1 | 16 | 1,93 |
| 112 - 126 | 1 | - | 5T860010008 | 100 | 1''1/2 | 50 | 1 | 16 | 1,82 |
| 112 - 126 | 1 | - | 5T860010010 | 100 | 2'' | 49 | 1 | 16 | 2,02 |
| 140 - 154 | 1 | - | 5T860012505 | 125 | 3/4'' | 50 | 1 | 16 | 1,72 |
| 140 - 154 | 1 | - | 5T860012506 | 125 | 1'' | 50 | 1 | 16 | 1,64 |
| 140 - 154 | 1 | - | 5T860012507 | 125 | 1''1/4 | 53 | 1 | 16 | 2,12 |
| 140 - 154 | 1 | - | 5T860012508 | 125 | 1''1/2 | 53 | 1 | 16 | 1,94 |
| 140 - 154 | 1 | - | 5T860012510 | 125 | 2'' | 57 | 1 | 16 | 2,32 |
| 168 - 184 | 1 | - | 5T860015010 | 150 | 2'' | 46 | 2 | 16 | 2,93 |
| 218 - 234 | 1 | - | 5T860020010 | 200 | 2'' | 46 | 2 | 16 | 3,04 |
| 40 - 50 | 1 | - | 5T86003004 | 30 | 1/2'' | 16 | 1 | 16 | 0,51 |
| 40 - 50 | 1 | - | 5T86003005 | 30 | 3/4'' | 16 | 1 | 16 | 0,42 |
| 48 - 55 | 1 | - | 5T86004005 | 40 | 3/4'' | 22 | 1 | 16 | 0,73 |
| 48 - 55 | 1 | - | 5T86004006 | 40 | 1'' | 22 | 1 | 16 | 0,74 |
| 60 - 68 | 1 | - | 5T86005005 | 50 | 3/4'' | 32 | 1 | 16 | 0,72 |
| 60 - 68 | 1 | - | 5T86005006 | 50 | 1'' | 32 | 1 | 16 | 0,73 |
| 60 - 68 | 1 | - | 5T86005007 | 50 | 1''1/4 | 27 | 1 | 16 | 1,25 |
| 60 - 68 | 1 | - | 5T86005008 | 50 | 1''1/2 | 27 | 1 | 16 | 1,14 |
| 72 - 80 | 1 | - | 5T86006005 | 60 | 3/4'' | 38 | 1 | 16 | 1,36 |
| 72 - 80 | 1 | - | 5T86006006 | 60 | 1'' | 38 | 1 | 16 | 1,35 |
| 72 - 80 | 1 | - | 5T86006007 | 60 | 1''1/4 | 43 | 1 | 16 | 1,66 |
| 72 - 80 | 1 | - | 5T86006008 | 60 | 1''1/2 | 43 | 1 | 16 | 1,55 |
| 76 - 84 | 1 | - | 5T86007005 | 70 | 3/4'' | 45 | 1 | 16 | 1,34 |
| 76 - 84 | 1 | - | 5T86007006 | 70 | 1'' | 45 | 1 | 16 | 1,21 |
| 76 - 84 | 1 | - | 5T86007007 | 70 | 1''1/4 | 48 | 1 | 16 | 1,62 |
| 76 - 84 | 1 | - | 5T86007008 | 70 | 1''1/2 | 48 | 1 | 16 | 1,51 |
| 88 - 104 | 1 | - | 5T86008005 | 80 | 3/4'' | 45 | 1 | 16 | 1,63 |
| 88 - 104 | 1 | - | 5T86008006 | 80 | 1'' | 45 | 1 | 16 | 1,54 |
| 88 - 104 | 1 | - | 5T86008007 | 80 | 1''1/4 | 40 | 1 | 16 | 1,81 |
| 88 - 104 | 1 | - | 5T86008008 | 80 | 1''1/2 | 40 | 1 | 16 | 1,71 |
| 88 - 104 | 1 | - | 5T86008010 | 80 | 2'' | 45 | 1 | 16 | 1,82 |
| 102 - 112 | 1 | - | 5T86009006 | 90 | 1'' | 55 | 1 | 16 | 1,61 |
| 102 - 112 | 1 | - | 5T86009007 | 90 | 1''1/4 | 50 | 1 | 16 | 1,93 |
| 102 - 112 | 1 | - | 5T86009008 | 90 | 1''1/2 | 50 | 1 | 16 | 1,85 |
