Drawing
Materials
| POSITION |
PART NAME |
MATERIAL |
N.° PIECES |
| 1 |
BODY |
BRASS CW617N UNI EN 12420 |
1 |
| 2 |
END CONNECTION |
BRASS CW617N UNI EN 12420 |
1 |
| 3 |
SPRING |
STEEL AISI 303 |
1 |
| 4 |
FLAT SEAT |
NBR |
1 |
| 5 |
OBSTRUCTOR |
FORTRON (POLYPHENYLENE SULFIDE) |
1 |
| 6 |
SUPPORT |
POM |
1 |
Table
| CODE |
SIZE |
DN |
UNITS PER BOX |
MASTER BOX |
I |
CH |
ØB |
ØC |
A |
KV |
PN |
KG |
| 10000003 |
3/8” |
10 |
20 |
160 |
11.4 |
21 |
20 |
27 |
47 |
1.8 |
40 |
0.08 |
| 10000004 |
1/2” |
15 |
15 |
120 |
15 |
26 |
25 |
34.5 |
59 |
7.9 |
40 |
0.14 |
| 10000005 |
3/4” |
20 |
10 |
80 |
16.3 |
32 |
31 |
42 |
65 |
13 |
40 |
0.21 |
| 10000006 |
1” |
25 |
10 |
40 |
19.1 |
39 |
38 |
49 |
75 |
19 |
25 |
0.33 |
| 10000007 |
1”1/4 |
32 |
6 |
24 |
21.4 |
49 |
48 |
61 |
83.5 |
29.5 |
25 |
0.55 |
| 10000008 |
1”1/2 |
40 |
4 |
16 |
21.4 |
55 |
54 |
73 |
89 |
44.6 |
16 |
0.76 |
| 10000010 |
2” |
50 |
2 |
8 |
25.7 |
68 |
67 |
87.5 |
101.5 |
61.3 |
16 |
1.15 |
| 10000012 |
2”1/2 |
65 |
2 |
4 |
30.2 |
83 |
83 |
111.5 |
121 |
77.5 |
12 |
2.13 |
| 10000014 |
3” |
80 |
2 |
4 |
33.3 |
98 |
98 |
133 |
136 |
121.9 |
12 |
3.3 |
| 10000018 |
4” |
100 |
- |
2 |
39.3 |
128 |
127 |
163 |
159 |
189.8 |
10 |
5.85 |
Notes
The accessory, item 110100, is available. See at page 311.
