Technical specifications
Drawing
Table
CODE SIZE DN UNITS PER BOX MASTER BOX ØP I ØA CH L H R PN KG
60076004 1/2” 15 10 40 12 12 15.5 25 78.5 125.5 50 16 0.39
60076005 3/4” 20 5 20 16.5 15 20.5 30 91.5 137.5 50 16 0.42
60076006 1” 25 10 20 18 18 25.5 38 100 151.5 50 16 0.57
Notes
The accessory, item 580900KR, is available. See at page 312.
