Drawing
Table
| CODE |
SIZE |
DN |
UNITS PER BOX |
MASTER BOX |
ØP |
I |
I1 |
CH |
ØH |
L |
H |
R |
KV |
PN |
KG |
| 60050004 |
1/2” |
15 |
15 |
60 |
16 |
15 |
10 |
25 |
31 |
80.5 |
48 |
50 |
8.5 |
16 |
0.26 |
| 60050005 |
3/4” |
20 |
10 |
40 |
21 |
16.3 |
12 |
31 |
38 |
91 |
51.5 |
50 |
17 |
16 |
0.38 |
| 60050006 |
1” |
25 |
10 |
20 |
27 |
19.1 |
14 |
38 |
46 |
103.5 |
55 |
50 |
27 |
16 |
0.6 |
Notes
The accessory, item 6404, is available. See at page 310.
